Glove80 Bluetooth Connection

By Xah Lee. Date: 2023-04-02. Last updated: 2023-11-11.

Show Bluetooth Connection Status

Press the MoErgo key. (lower left key on left-hand-side)

glove80 status 202301 NXryC — Glove80 Status Lights

glove80 lights 2023-11-06 b6zpc

The 4 keys on the left of thumb indicates 4 Bluetooth profiles:

 Shift Control Layer
Bksp Delete Alt

The Alt indicate USB wired connection.

glove80 bluetooth keys 2023-01 — glove80 bluetooth left thumb keys 2023-01

Color meaning:

White: paired, connected, and is the current output device
Green: paired, connected, but not being used for output.
Red: paired but not connected
Purple: not paired.

Connecting to Bluetooth

you can connect up to 4 bluetooth devices.

To connect:

Press and release the MoErgo key. Those colored purple are unpaired bluetooth profiles.
Select a unpaired bluetooth profile, by: Hold the MoErgo key and press one of Shift or Ctrl or Backspace or Delete ⌦. (they are the 4 keys on the left of the left thumb area.)
Now goto your operating system, bluetooth settings, glove80 shoud show up there. Select connect.

Reset Bluetooth

To reset all Bluetooth profiles, hold the MoErgo key and press F1
